71M6513/71M6513H
A Maxim Integrated Products Brand
3 -Phase      Energy Meter IC
DATA SHEET
SEPTEMBER 2011
Interrupts
The 80515 provides 11 interrupt sources with four priority levels. Each source has its own request flag(s) located in a special
function register ( TCON , IRCON , and SCON ). Each interrupt requested by the corresponding flag can be individually enabled or
disabled by the enable bits in SFRs IEN0 , IEN1 , and IEN2 .
External interrupts are the interrupts external to the 80515 core, i.e. signals that originate in other parts of the
71M6513/6513H, for example the CE, DIO, RTC EEPROM interface, comparators.
Interrupt Overview: When an interrupt occurs, the MPU will vector to the predetermined address as shown in Table 50. Once
interrupt service has begun, it can be interrupted only by a higher priority interrupt. The interrupt service is terminated by a
return from instruction, "RETI". When a RETI instruction is performed, the processor will return to the instruction that would
have been next when the interrupt occurred.
When the interrupt condition occurs, the processor will also indicate this by setting a flag bit. This bit is set regardless of
whether the interrupt is enabled or disabled. Each interrupt flag is sampled once per machine cycle, then samples are polled
by the hardware. If the sample indicates a pending interrupt when the interrupt is enabled, then the interrupt request flag is set.
On the next instruction cycle, the interrupt will be acknowledged by hardware forcing an LCALL to the appropriate vector
address, if the following conditions are met:
?
?
?
No interrupt of equal or higher priority is already in progress.
An instruction is currently being executed and is not completed.
The instruction in progress is not RETI or any write access to the registers IEN0 , IEN1 , IEN2 , IP0 or IP1 .
Interrupt response will require a varying amount of time depending on the state of the MPU when the interrupt occurs. If the
MPU is performing an interrupt service with equal or greater priority, the new interrupt will not be invoked. In other cases, the
response time depends on the current instruction. The fastest possible response to an interrupt is 7 machine cycles. This
includes one machine cycle for detecting the interrupt and six cycles to perform the LCALL.
? 2005-2011 Teridian Semiconductor Corporation
Page: 31 of 104
